The fertilizer screening machine is mainly used for grading the particle size and separating impurities of various fertilizers.
With “solving fertilizer screening pain points, ensuring uniform particles & high efficiency” as the core goal, our fertilizer screening machines integrate targeted technologies:
For sticky organic fertilizer (post-fermentation, moisture 15%-20%): Adopt “high-frequency vibration + anti-stick screen mesh” design—vibration frequency (1500-3000 rpm) breaks up agglomerates, and Teflon-coated screen mesh (1-5mm aperture) prevents fertilizer adhesion, screening efficiency ≥98%;For brittle biological fertilizer (microbial granules, easy to crush): Use “low-amplitude vibration + soft rubber screen frame”—amplitude adjustable (1-5mm) reduces particle collision, damage rate ≤2% (vs. 8%-10% for ordinary screens);For corrosive chemical fertilizer (ammonium phosphate, urea): Screen mesh and frame made of 304/316L stainless steel—resists acid/alkali corrosion, service life extended to 5-8 years.
Multi-layer screen design (2-4 layers, optional aperture 0.5-10mm): Realizes one-time classification of “oversized lumps (＞5mm) + qualified granules (2-5mm) + fine powder (＜2mm)”—oversized lumps are returned to crusher for reprocessing, fine powder is recycled to mixer, material utilization rate ≥99%;Built-in magnetic impurity remover (for chemical/organic fertilizer): Adsorbs metal scraps (nails, iron filings) from raw materials, avoiding damage to downstream packaging machines or mixer blades.
Equipped with “screen self-cleaning system”—rotary brush (for mesh cleaning) and air-blowing device (for fine powder removal) work synchronously with vibration, reducing manual cleaning frequency by 80%;Quick-screen replacement structure: Screen mesh can be disassembled in 15-30 minutes (vs. 1-2 hours for ordinary screens), convenient for switching between different fertilizer particle specifications.
PLC control system connects with upstream crusher/fermenter and downstream mixer/coater—automatically adjusts vibration frequency and feeding speed based on incoming material volume (detected by level sensors), avoiding screen overload;Energy-efficient vibration motor (IE3 level) + optimized vibration structure reduce energy consumption by 15%-20% vs. ordinary screening machines, suitable for 24/7 continuous production.
Sealed screening chamber + dust-collecting port (connectable to fertilizer line dust collectors): Prevents dust leakage during screening (dust concentration ≤5mg/m³), complying with GBZ 2.1 occupational health standards;Emergency stop button and overload protection: Triggers auto-shutdown if screen is blocked or motor overheats, preventing equipment damage.
Our fertilizer screening machines cover the “particle classification & impurity removal” link of various fertilizer production lines, matching different fertilizer types:
High-frequency vibrating screens (2-layer, 3mm/5mm aperture) for fermented manure/straw mixtures—separates unfermented lumps (＞5mm) and qualified granules (2-5mm), improving organic fertilizer uniformity;Example: A 30,000-ton/year organic fertilizer plant uses our screen—qualified product rate increased from 82% to 97%, reducing raw material waste by 15%.
Multi-layer vibrating screens (3-layer, 2mm/4mm/6mm aperture) for post-granulation NPK fertilizer—classifies fine powder (＜2mm, recycled), qualified granules (2-4mm, for packaging), and oversized granules (＞6mm, re-crushed);Example: A 50,000-ton/year compound fertilizer plant reduced unqualified granule rate from 10% to 1.2%, passing national quality inspections.
Low-amplitude vibrating screens (1-layer, 2mm aperture) for microbial fertilizer—avoids granule crushing, ensuring viable bacteria count ≥200 million/g (GB/T 23473 standard);
Example: A U.S. biological fertilizer enterprise uses our screen—microbial survival rate after screening reaches 96%, meeting EPA organic product requirements.
Vibrating screens with magnetic separators for straw/corn cob raw materials—removes stones, metal scraps, and large impurities before crushing/fermentation, protecting upstream crushers;
Example: A Chinese straw-based organic fertilizer workshop reduced crusher maintenance frequency by 40% after using our impurity-removing screen.
Mini vibrating screens (capacity 0.5-2 tons/hour) for small workshops (e.g., family farm organic fertilizer production);High-capacity linear vibrating screens (capacity 5-30 tons/hour) for large plants—supports 24/7 continuous screening, matching high-speed granulation lines.
Adopt “factory direct supply + fertilizer line customization” with no middlemen, cutting procurement costs by 18%-30% vs.
As a screening machine supplier specialized in fertilizer industry, we provide solutions tailored to production needs:
A 50,000-ton/year compound fertilizer plant in China reduced reprocessing costs by $60,000/year with our multi-layer screen;
A Brazilian organic fertilizer enterprise solved screen adhesion issues—screening efficiency increased from 85% to 99%, production capacity up 14%;
A European biological fertilizer brand used our low-amplitude screen—microbial product qualification rate reached 99.5%, expanding to 8 EU countries.
Whether you need to classify organic fertilizer granules, remove impurities from compound fertilizer raw materials, or protect brittle biological fertilizer particles, we provide screening machines that match your production line. Contact us for free fertilizer sample screening tests (verifying efficiency and particle damage rate) and customized quotes—our team helps you improve product uniformity, reduce waste, and enhance downstream processing efficiency.
