What is a self-cleaning crusher?

What is a self-cleaning crusher?

Core features of self-cleaning crusher: It comes with a self-cleaning and anti blocking structure, which automatically cleans the screen mesh and the adhesive materials in the crushing chamber during operation, reducing machine blockage and adhesive materials, and reducing manual cleaning frequency. It is commonly used in the organic fertilizer, feed, chemical, pharmaceutical, and environmental protection industries and is also commonly referred to as self-cleaning crusher or anti blocking crusher.
Pay attention to differentiation: Do not confuse with self-priming crusher, self-priming is negative pressure automatic feeding; Self cleaning is the automatic cleaning of the chamber/screen to prevent clogging.

Working principle of self-cleaning crusher

When a regular crusher crushes, fine and wet materials are prone to sticking to the inner wall of the sieve, causing blockage and a decrease in production.
The self-cleaning crusher chamber is equipped with a cleaning mechanism (cleaning hammer, cleaning rotor, reverse scraping device). While the grinding rotor rotates, the cleaning component continuously scrapes the inside of the screen, scraping off the material adhered to the screen and chamber wall. The material continues to be crushed, sieved and discharged, achieving automatic cleaning of the chamber during operation without stopping the machine to disassemble and clean the screen.

Main structure of self-cleaning crusher

Host casing, grinding rotor (hammer/toothed disc)
Self cleaning components (core): screen cleaning hammer, cleaning scraper, eccentric drum (horizontal model)
Screen mesh (replaceable, controlling discharge particle size)
Inlet and outlet; Optional dust removal and Shakron aggregate device
Drive motor, transmission mechanism

Main classification and application scenarios of self-cleaning crushers

1. Horizontal drum self-cleaning crusher (mainstream in the organic fertilizer industry)
Suitable for semi wet materials: chicken manure, pig manure, fermented organic fertilizers, sludge, humus soil, high moisture content, viscous materials, solving the pain point of wet material clogging in screening machines, commonly used in organic fertilizer production lines, directly crushing fermented materials without drying.
2. Vertical self-cleaning universal crusher
Commonly used for brittle materials in medicinal herbs, food, and chemical industries, the stainless steel GMP model comes with self cleaning and dust removal, resulting in minimal dust and suitable for dry powder processing.
3. Environmentally friendly sewage self-cleaning crusher machine
Sewage channel, crushing fibers, cloth strips and debris, rake teeth automatically clean the grille, anti entanglement, mostly used for water treatment, less used for solid material crushing.

Core advantages of self-cleaning crusher

Anti clogging and non stick screening: Continuous production of wet and sticky materials without frequent shutdowns for screen cleaning
High continuous production efficiency, suitable for assembly line matching
Reduce manual maintenance and minimize the workload of dismantling and cleaning the screen mesh
The lifespan of the sieve is longer, reducing the high-temperature wear of the paste sieve
